The Pro VP™ is a embedded stand-alone video player solution especially designed for playback to any ProCommander® Series and ProCommander® X Series device.
Introducing the Pro VP™, an embedded stand-alone video player solution providing two HDMI outputs, each supporting frame synchronous Full-HD @ 30 fps for 3D cinema projection or dual screen.
Pro VP™ features MIDI and Art-Net time code for synchronization of external equipment and multi-display solutions. A custom, friendly web configuration interface is also provided.
The Pro VP™ is available in three version:
- Pro VP™
- Pro VP™ Videowall 3D
- Pro VP™ Multi Timeline
Special Features
- 2x Full-HD@30fps; 3D ready
- Dolby 5.1 via HDMI Output
- UDP Command Interface
- 2x Ethernet
- 2x RS-232
| Features | Pro VP™ Series | |||||
|---|---|---|---|---|---|---|
| SPM = Single Player Mode
MPM = Multi Player Mode |
Pro VP™ | Pro VP™ Videowall 3D |
Pro VP™ Multi Timeline |
|||
| SPM | MPM | SPM | MPM | SPM | MPM | |
| Video Playback | x | x | x | x | x | x |
| UDP Command Interface | x | x | x | x | x | x |
| UDP/Serial Message Provider | x | x | x | x | x | x |
| Scripting Interface | x | x | x | x | x | x |
| Playlist Support | x | x | x | x | x | x |
| MIDI Timecode | x | x | x | x | x | x |
| Art-Net Timecode | x | x | x | x | x | x |
| Event Report | x | x | x | x | x | x |
| Position Report | x | x | x | x | x | x |
| Static EDID Support | x | x | x | x | x | x |
| Multi Channel Audio Support*
HDMI-1 (8 Channels) HDMI-2 (8 Channels) LINE-OUT (2 Channels) |
x | x | x | x | x | x |
| Shutter Support for Resolution Switches | x | x | x | x | x | x |
| Overlay Support | 1x static** | – | 1x static*** | – | x | x |
| Animation for layer alpha value and audio volume support | x | x | x | x | x | x |
| Dual Sync Display Playback Support | – | – | x | – | x | – |
| Multiple Timelines | – | – | – | – | x | x |
| Unlimited Video Layer Support | – | – | – | – | x | x |
| Dynamic Modification of all layer properties (position, size, etc.) as well as animation support for these properties | – | – | – | – | x | x |
| * = depends on connected screen/monitor
** = image *** = image/ video |
||||||
| Features | Pro VP™ Series | |||||
|---|---|---|---|---|---|---|
| SPM = Single Player Mode
MPM = Multi Player Mode |
Pro VP™ | Pro VP™ Videowall 3D |
Pro VP™ Multi Timeline |
|||
| SPM | MPM | SPM | MPM | SPM | MPM | |
| Independent Player | 1 | 2 | 1 | 2 | 1 | 2 |
| Video Output | 1 | 2 | 1 or 2 | 2 | 1 or 2 | 2 |
| Independent Timeline per Player | 1 | 1 | 1 | 1 | 1+ | 1+ |
If you have any further questions or if you want to order a Weigl Pro VP™ please contact us.
