Weigl Hardware Configurator ist das Konfigurationswerkzeug für die Weigl ProCommander® X Series, Weigl ProCommander® Series und Pro I/O™ Series. Weigl Hardware Configurator ist erhältlich für Windows und MacOS.
ProCommander® AX
| Ethernet |
2 |
|---|---|
| WEM-NET |
2 |
| I/O-NET |
2 |
| Art-Net Supported |
1 |
| Mini USB |
1 |
| Display Graphic |
1 |
| Digital In |
8* |
| Digital Out Negative (NPN) |
4 |
| RS-485 |
1 |
| CAN |
1 |
| DMX Out |
512* |
| Analog In |
4* |
| Analog Out |
4 |
| Analog Closed Loop |
4 |
| Internal Storage microSD |
1 |
| Amplifier (HP Class D) |
1 |
| Audio Klinke 1/8" |
1 |
| Polyphonic Audio |
1 |
| Audio Lautsprecher 2pol. |
2 |
| Wi-Fi |
1 |
| Stand-alone |
1 |
ProCommander® HXb
| Ethernet |
1 |
|---|---|
| WEM-NET |
2 |
| I/O-NET |
2 |
| Art-Net Supported |
1 |
| Display Graphic |
1 |
| Digital In |
16 |
| Digital Out Negative (NPN) |
16* |
| RS-232 |
3 |
| RS-485 |
1 |
| CAN |
1 |
| DMX In |
512 |
| DMX Out |
512 |
| Servo Out |
8 |
| Analog In |
8 |
| Analog Out |
4 |
| Analog Closed Loop |
4 |
| SMPTE Time Code In |
1 |
| SMPTE Time Code Out |
1 |
| Real Time Clock |
1 |
| Amplifier (HP Class D) |
1 |
| Audio Sub-D 25pol. |
1 |
| Polyphonic Audio |
1 |
| Stand-alone |
1 |
ProCommander® 4
| Ethernet |
1 |
|---|---|
| WEM-NET |
2 |
| I/O-NET |
2 |
| Art-Net Supported |
1 |
| Mini USB |
1 |
| Display LCD |
1 |
| Digital In |
16 |
| Digital Out Negative (NPN) |
16 |
| RS-232 |
2 |
| RS-485 |
2 |
| DMX In |
512 |
| DMX Out |
512 |
| Servo Out |
4 |
| Analog In |
8 |
| Analog Out |
4 |
| SMPTE Time Code In |
Opt. |
| SMPTE Time Code Out |
Opt. |
| Real Time Clock |
1 |
| Internal Storage microSD |
1 |
| Amplifier (HP Class D) |
1 |
| Audio Klinke 1/8" |
1 |
| Audio Lautsprecher 2pol. |
2 |
| Stand-alone |
1 |
ProCommander® HXi
| Ethernet |
2 |
|---|---|
| WEM-NET |
2 |
| I/O-NET |
2 |
| Art-Net Supported |
1 |
| Display Graphic |
1 |
| Digital In |
16 |
| Digital Out Negative (NPN) |
16* |
| RS-232 |
3 |
| RS-485 |
1 |
| CAN |
2 |
| DMX In |
512 |
| DMX Out |
4x DMX-OUT Universe, 512 |
| Servo Out |
4 |
| Analog Out |
4 |
| SMPTE Time Code In |
1 |
| SMPTE Time Code Out |
1 |
| Real Time Clock |
1 |
| Amplifier (HP Class D) |
1 |
| Polyphonic Audio |
1 |
| Stand-alone |
1 |
ProCommander® HX
| Ethernet |
2 |
|---|---|
| WEM-NET |
2 |
| I/O-NET |
2 |
| Art-Net Supported |
1 |
| Mini USB |
1 |
| Display Graphic |
1 |
| Digital In |
16 |
| Digital Out Negative (NPN) |
16* |
| RS-232 |
4 |
| RS-485 |
1 |
| CAN |
1 |
| DMX In |
512 |
| DMX Out |
512 |
| Servo Out |
8 |
| Analog In |
12 |
| Analog Out |
4 |
| Analog Closed Loop |
4 |
| SMPTE Time Code In |
1 |
| SMPTE Time Code Out |
1 |
| Real Time Clock |
1 |
| Internal Storage SD |
1 |
| Amplifier (HP Class D) |
1 |
| Audio Sub-D 25pol. |
2 |
| Polyphonic Audio |
1 |
| Microphone In (1/4") |
2 |
| Line In (1/4") |
1 |
| Stand-alone |
1 |
